Bilstein 5100 Lift Kit (Up to 2.5") | 2003-2009 GX470

Bilstein 5100 struts and shocks paired with American Spring Company (ASC) lift coils. The coils make the lift, so the front 5100 circlip stays on the lowest perch. You keep full up-travel and down-travel, and you get a better ride than a stock coil with added preload.

What's in the box

• (2) Bilstein 5100 3-notch adjustable front struts
• (2) Bilstein 5100 rear shocks
• (2) ASC front coil springs (your choice below)
• (2) ASC rear coil springs (your choice below)
• Assembly included

Front lift options

• 1" lift [ASC 5121]
• 2.5" lift at stock weight, 2" with added weight [ASC 5131]
• 2.5" lift with added front weight [ASC 5132]

Rear lift options

• 2" lift [ASC 5221]
• 2.5" lift at stock weight, 2" with added weight [ASC 5211]
• 2.5" lift with added rear weight [ASC 5222]

Recommended add-ons

• Extended brake lines and bump stops: keep slack at full droop and protect the shocks.
• Air-to-coil conversion: replaces factory rear air suspension with coil springs.

Install time

• Less than 4 hours
• About 6 hours with upper control arms

Please note

• Lift heights are averages. Final ride height depends on your vehicle, its load, and the condition of its suspension.
• Lift heights assume the front circlip is on the lowest perch. Do not raise the perch with lift coils installed. This can damage the strut and voids the manufacturer warranty.

• Vehicles with factory rear air suspension need an air-to-coil conversion kit.
• 2WD lift heights can differ because the front end is lighter.
• ASC or OME coils are used, depending on availability.
